Ekran 4.3 inča HDMI LCD (B), 800×480, IPS, osetljiv na dodir

Opis

SKU: 15932
Part Number: 4.3inch HDMI LCD (B)

4.3inch, 800×480, Capacitive Touch Screen LCD, HDMI Interface, Supports Multi Mini-PCs, Multi Systems

Features

  • IPS screen, 800×480 hardware resolution, configurable by software (up to 1920×1080)
  • Supports popular mini PCs such as Raspberry Pi, Jetson Nano, BB Black, Banana Pi, as well as general desktop computers
    • When works with Raspberry Pi, supports Raspbian/Ubuntu/Kali/Retropie/WIN10 IOT, driver free
    • When work as a computer monitor, supports Windows 10/8.1/8/7, five-points touch, and driver free
  • Multi languages OSD menu, for power management, brightness/contrast adjustment, etc.
  • 3.5mm audio jack, speaker connector, supports HDMI audio output

Using with Game Consoles

PART NUMBER MICROSOFT XBOX SONY PS4 NINTENDO SWITCH
DISPLAY SOUND DISPLAY SOUND DISPLAY SOUND
3.5inch HDMI LCD
4.3inch HDMI LCD (B)
5inch HDMI LCD (G)
5inch HDMI LCD (H)
7inch HDMI LCD × × ×
7inch HDMI LCD (H)
10.1inch HDMI LCD × × ×
10.1inch HDMI LCD (B) × × × × ×
10.1inch HDMI LCD (H) × ×
11.6inch HDMI LCD (H)
13.3inch HDMI LCD (H) V2
15.6inch HDMI LCD (H)

Note:

  • Limited by the game console OS, the touch function is unavailable.
  • Sound support means, it is possible for the game console to output sound signal via LCD embedded speaker, external speaker interface, or earphone jack.

External Dimension

4.3inch HDMI LCD (B) dimension

PACKAGE CONTENT

Weight: 0.185 kg

Note: Raspberry Pi and Speaker (8Ω 5W) are NOT included.

  1. 4.3inch HDMI LCD (B) x1
  2. HDMI cable x1
  3. USB type A plug to micro B plug cable x1
  4. HDMI adapter (B) x1
  5. USB adapter (B) x1
  6. HDMI to Micro HDMI adapter (C) x1
  7. USB adapter (C) x1
  8. Screws pack x1
1
2
3
4
5
6
7
8

Wiki : www.waveshare.com/wiki/4.3inch_HDMI_LCD_(B)

Deklaracija

Šifra: w15932
Naziv: Ekran 4.3 inča HDMI LCD, 800×480
Vrsta: Waveshare
Zemlja porekla: Kina
Zemlja uvoza: Kina
Uvoznik: MALINA 314 doo, Beograd
telefon: 061-640-2013
